LQW04AN6N2D00D
TOKO / Murata
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 6.2NH 390MA 190 MOHM
- CategoryFixed Inductors
- Datasheet LQW04AN6N2D00D Datasheet
-
ECAD Model
- Share
In Stock: 122
Can ship immediately
Pricing:
- 1$0.15429
- 10,000$0.15429
Quote It
Technical Details
- Series:LQW04
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Wirewound
- Material - Core:-
- Inductance:6.2 nH
- Tolerance:±0.5nH
- Current Rating (Amps):390 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):190mOhm Max
- Q @ Freq:20 @ 250MHz
- Frequency - Self Resonant:9GHz
- Ratings:-
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:100 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:0302 (0804 Metric)
- Supplier Device Package:03015 (0804 Metric)
- Size / Dimension:0.031" L x 0.016" W (0.80mm x 0.40mm)
- Height - Seated (Max):0.018" (0.45mm)
