SDR0302-390KL

Technical Details

• Series:SDR0302
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• Type:Wirewound
• Material - Core:Ferrite
• Inductance:39 µH
• Tolerance:±10%
• Current Rating (Amps):380 mA
• Current - Saturation (Isat):450mA
• Shielding:Unshielded
• DC Resistance (DCR):1.12Ohm Max

• Q @ Freq:24 @ 2.52MHz
• Frequency - Self Resonant:18MHz
• Ratings:-
• Operating Temperature:-40°C ~ 125°C
• Inductance Frequency - Test:1 kHz
• Features:-
• Mounting Type:Surface Mount
• Package / Case:Nonstandard
• Supplier Device Package:-
• Size / Dimension:0.118" L x 0.110" W (3.00mm x 2.80mm)
• Height - Seated (Max):0.110" (2.80mm)
