AIUR-04-392J
Abracon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 3.9MH 50MA 13 OHM TH
- CategoryFixed Inductors
- Datasheet AIUR-04-392J Datasheet
-
ECAD Model
- Share
In Stock: 109
Can ship immediately
Pricing:
- 1$0.2448
- 1,000$0.2448
Quote It
Technical Details
- Series:AIUR-04
- Package:Bulk
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:3.9 mH
- Tolerance:±5%
- Current Rating (Amps):50 mA
- Current - Saturation (Isat):50mA
- Shielding:Unshielded
- DC Resistance (DCR):13Ohm Max
- Q @ Freq:40 @ 252kHz
- Frequency - Self Resonant:700kHz
- Ratings:-
- Operating Temperature:-25°C ~ 85°C
- Inductance Frequency - Test:252 kHz
- Features:-
- Mounting Type:Through Hole
- Package / Case:Radial, Vertical Cylinder
- Supplier Device Package:-
- Size / Dimension:0.335" Dia (8.50mm)
- Height - Seated (Max):0.441" (11.20mm)
