AIUR-05-330K
Abracon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 33UH 1A 92 MOHM TH
- CategoryFixed Inductors
- Datasheet AIUR-05-330K Datasheet
-
ECAD Model
- Share
In Stock: 179
Can ship immediately
Pricing:
- 1$0.2448
- 1,000$0.2448
Quote It
Technical Details
- Series:AIUR-05
- Package:Bulk
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:33 µH
- Tolerance:±10%
- Current Rating (Amps):1 A
- Current - Saturation (Isat):1.3A
- Shielding:Unshielded
- DC Resistance (DCR):92mOhm Max
- Q @ Freq:10 @ 2.52kHz
- Frequency - Self Resonant:10MHz
- Ratings:-
- Operating Temperature:-25°C ~ 85°C
- Inductance Frequency - Test:2.52 kHz
- Features:-
- Mounting Type:Through Hole
- Package / Case:Radial, Vertical Cylinder
- Supplier Device Package:-
- Size / Dimension:0.335" Dia (8.50mm)
- Height - Seated (Max):0.354" (9.00mm)
