B82144A2105J009
TDK EPCOS
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 1MH 200MA 3.8 OHM TH
- CategoryFixed Inductors
- Datasheet B82144A2105J009 Datasheet
-
ECAD Model
- Share
In Stock: 197
Can ship immediately
Pricing:
- 1$0.2449
- 10,000$0.2449
Quote It
Technical Details
- Series:LBC
- Package:Tape & Box (TB)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:1 mH
- Tolerance:±5%
- Current Rating (Amps):200 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):3.8Ohm Max
- Q @ Freq:60 @ 252kHz
- Frequency - Self Resonant:1.2MHz
- Ratings:-
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Through Hole
- Package / Case:Axial
- Supplier Device Package:-
- Size / Dimension:0.205" Dia x 0.472" L (5.20mm x 12.00mm)
- Height - Seated (Max):-
