NRS6012T220MMGJV
TAIYO YUDEN
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 22UH 650MA 558 MOHM
- CategoryFixed Inductors
- Datasheet NRS6012T220MMGJV Datasheet
-
ECAD Model
- Share
In Stock: 130
Can ship immediately
Pricing:
- 1$0.2482
- 1,000$0.2482
- 3,000$0.2336
- 5,000$0.2263
- 10,000$0.219
- 25,000$0.2117
Quote It
Technical Details
- Series:NR, S Type
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:22 µH
- Tolerance:±20%
- Current Rating (Amps):650 mA
- Current - Saturation (Isat):760mA
- Shielding:Shielded
- DC Resistance (DCR):558mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:12MHz
- Ratings:AEC-Q200
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.236" L x 0.236" W (6.00mm x 6.00mm)
- Height - Seated (Max):0.047" (1.20mm)
