RLB1314-100ML
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 10UH 3.2A 15 MOHM TH
- CategoryFixed Inductors
- Datasheet RLB1314-100ML Datasheet
-
ECAD Model
- Share
In Stock: 111
Can ship immediately
Pricing:
- 1$0.2618
- 300$0.2618
Quote It
Technical Details
- Series:RLB
- Package:Bulk
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:10 µH
- Tolerance:±20%
- Current Rating (Amps):3.2 A
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):15mOhm Max
- Q @ Freq:140 @ 2.52MHz
- Frequency - Self Resonant:26MHz
- Ratings:-
- Operating Temperature:-40°C ~ 105°C
- Inductance Frequency - Test:1 kHz
- Features:-
- Mounting Type:Through Hole
- Package / Case:Radial, Vertical Cylinder
- Supplier Device Package:-
- Size / Dimension:0.461" Dia (11.70mm)
- Height - Seated (Max):0.512" (13.00mm)
