AX104R-2R5
Triad Magnetics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 2.5UH 6.1A 10 MOHM SMD
- CategoryFixed Inductors
- Datasheet AX104R-2R5 Datasheet
-
ECAD Model
- Share
In Stock: 168
Can ship immediately
Pricing:
- 1$0.476
- 800$0.46359
Quote It
Technical Details
- Series:AX104R
- Package:Box
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:2.5 µH
- Tolerance:±30%
- Current Rating (Amps):6.1 A
- Current - Saturation (Isat):-
- Shielding:Shielded
- DC Resistance (DCR):10mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-40°C ~ 85°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:SMD
- Size / Dimension:0.409" L x 0.406" W (10.40mm x 10.30mm)
- Height - Seated (Max):0.157" (4.00mm)
