SRU1048A-221Y
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 220UH 800MA 455MOHM SM
- CategoryFixed Inductors
- Datasheet SRU1048A-221Y Datasheet
-
ECAD Model
- Share
In Stock: 130
Can ship immediately
Pricing:
- 1$0.5336
- 2,400$0.4785
Quote It
Technical Details
- Series:SRU1048A
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:220 µH
- Tolerance:±30%
- Current Rating (Amps):800 mA
- Current - Saturation (Isat):700mA
- Shielding:Shielded
- DC Resistance (DCR):455mOhm Max
- Q @ Freq:20 @ 796kHz
- Frequency - Self Resonant:4MHz
- Ratings:AEC-Q200
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.394" L x 0.394" W (10.00mm x 10.00mm)
- Height - Seated (Max):0.201" (5.10mm)
