IHLP2020BZERR33M11
Vishay / Dale
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 330NH 13A 5.9 MOHM SMD
- CategoryFixed Inductors
- Datasheet IHLP2020BZERR33M11 Datasheet
-
ECAD Model
- Share
In Stock: 125
Can ship immediately
Pricing:
- 1$1.19
- 2,000$0.992
- 4,000$0.96
- 6,000$0.928
- 10,000$0.896
Quote It
Technical Details
- Series:IHLP-2020BZ-11
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Molded
- Material - Core:-
- Inductance:330 nH
- Tolerance:±20%
- Current Rating (Amps):13 A
- Current - Saturation (Isat):7.5A
- Shielding:Shielded
- DC Resistance (DCR):5.9mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:108MHz
- Ratings:-
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.216" L x 0.204" W (5.49mm x 5.18mm)
- Height - Seated (Max):0.079" (2.00mm)
