B82471A1224K000

Technical Details

• Series:B82471A1
• Package:Tape & Reel (TR)
• Part Status:Not For New Designs
• Type:Wirewound
• Material - Core:Ferrite
• Inductance:220 µH
• Tolerance:±10%
• Current Rating (Amps):350 mA
• Current - Saturation (Isat):380mA
• Shielding:Unshielded
• DC Resistance (DCR):1.57Ohm Max

• Q @ Freq:-
• Frequency - Self Resonant:-
• Ratings:-
• Operating Temperature:-55°C ~ 150°C
• Inductance Frequency - Test:100 kHz
• Features:-
• Mounting Type:Surface Mount
• Package / Case:Nonstandard
• Supplier Device Package:-
• Size / Dimension:0.240" L x 0.220" W (6.10mm x 5.60mm)
• Height - Seated (Max):0.193" (4.90mm)
