SRR1205-500YL
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 50UH 1.5A 200 MOHM SMD
- CategoryFixed Inductors
- Datasheet SRR1205-500YL Datasheet
-
ECAD Model
- Share
In Stock: 162
Can ship immediately
Pricing:
- 1$0.5544
- 600$0.518
Quote It
Technical Details
- Series:SRR1205
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:50 µH
- Tolerance:±15%
- Current Rating (Amps):1.5 A
- Current - Saturation (Isat):2.8A
- Shielding:Shielded
- DC Resistance (DCR):200mOhm Max
- Q @ Freq:18 @ 2.52MHz
- Frequency - Self Resonant:7MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:1 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.500" L x 0.500" W (12.70mm x 12.70mm)
- Height - Seated (Max):0.217" (5.50mm)
