PA3779.181HLT
PulseLarsen Antenna
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 180NH 56A 0.29 MOHM
- CategoryFixed Inductors
- Datasheet PA3779.181HLT Datasheet
-
ECAD Model
- Share
In Stock: 109
Can ship immediately
Pricing:
- 1$0.5859
- 3,000$0.5859
Quote It
Technical Details
- Series:PA3779.XXXHL
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:-
- Material - Core:-
- Inductance:180 nH
- Tolerance:±15%
- Current Rating (Amps):56 A
- Current - Saturation (Isat):65A
- Shielding:Unshielded
- DC Resistance (DCR):0.29mOhm
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-40°C ~ 130°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.449" L x 0.276" W (11.40mm x 7.00mm)
- Height - Seated (Max):0.315" (8.00mm)
