CDR6D23MNNP-560NC
Sumida Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 56UH 510MA 481.2 MOHM
- CategoryFixed Inductors
- Datasheet CDR6D23MNNP-560NC Datasheet
-
ECAD Model
- Share
In Stock: 198
Can ship immediately
Pricing:
- 1$0.576
- 1,500$0.576
Quote It
Technical Details
- Series:CDR6D23MN
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:-
- Material - Core:Ferrite
- Inductance:56 µH
- Tolerance:±25%
- Current Rating (Amps):510 mA
- Current - Saturation (Isat):750mA
- Shielding:Shielded
- DC Resistance (DCR):481.2mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-40°C ~ 105°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.256" L x 0.256" W (6.50mm x 6.50mm)
- Height - Seated (Max):0.098" (2.50mm)
