486R8C
Murata Power Solutions
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 6.8UH 4.7A 39.9 MOHM
- CategoryFixed Inductors
- Datasheet 486R8C Datasheet
-
ECAD Model
- Share
In Stock: 109
Can ship immediately
Pricing:
- 1$0.58
- 600$0.58
Quote It
Technical Details
- Series:4800
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Wirewound
- Material - Core:-
- Inductance:6.8 µH
- Tolerance:-
- Current Rating (Amps):4.7 A
- Current - Saturation (Isat):-
- Shielding:Shielded
- DC Resistance (DCR):39.9mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-40°C ~ 85°C
- Inductance Frequency - Test:10 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard, 4 Lead
- Supplier Device Package:-
- Size / Dimension:0.480" L x 0.480" W (12.20mm x 12.20mm)
- Height - Seated (Max):0.244" (6.20mm)
