PM3316S-2R2M-RC
J.W. Miller / Bourns- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 2.2UH 3.1A 27 MOHM SMD
- CategoryFixed Inductors
- Datasheet PM3316S-2R2M-RC Datasheet
-
ECAD Model
- Share
In Stock: 166
Can ship immediately
Pricing:
- 1$0.612
- 500$0.612
Quote It
Technical Details
- Series:PM3316S
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:2.2 µH
- Tolerance:±20%
- Current Rating (Amps):3.1 A
- Current - Saturation (Isat):6.1A
- Shielding:Shielded
- DC Resistance (DCR):27mOhm
- Q @ Freq:25 @ 7.96MHz
- Frequency - Self Resonant:90MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:1 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.500" L x 0.394" W (12.70mm x 10.00mm)
- Height - Seated (Max):0.205" (5.20mm)
