ECS-MPI4040R2-6R8-R
ECS Inc. International
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 6.8UH 1.8A 189.6 MOHM
- CategoryFixed Inductors
- Datasheet ECS-MPI4040R2-6R8-R Datasheet
-
ECAD Model
- Share
In Stock: 181
Can ship immediately
Pricing:
- 1$0.6803
- 4,500$0.6803
Quote It
Technical Details
- Series:ECS-MPI4040
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:-
- Material - Core:-
- Inductance:6.8 µH
- Tolerance:±20%
- Current Rating (Amps):1.8 A
- Current - Saturation (Isat):3.4A
- Shielding:Shielded
- DC Resistance (DCR):189.6mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:AEC-Q200
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.177" L x 0.161" W (4.50mm x 4.10mm)
- Height - Seated (Max):0.059" (1.50mm)
