PM1608-102M-RC

Technical Details

• Series:PM1608
• Package:Tape & Reel (TR)
• Part Status:Active
• Type:Wirewound
• Material - Core:Ferrite
• Inductance:1 mH
• Tolerance:±20%
• Current Rating (Amps):70 mA
• Current - Saturation (Isat):100mA
• Shielding:Unshielded
• DC Resistance (DCR):13.8Ohm Max

• Q @ Freq:71 @ 252kHz
• Frequency - Self Resonant:2MHz
• Ratings:-
• Operating Temperature:-40°C ~ 125°C
• Inductance Frequency - Test:252 kHz
• Features:-
• Mounting Type:Surface Mount
• Package / Case:Nonstandard
• Supplier Device Package:-
• Size / Dimension:0.260" L x 0.175" W (6.60mm x 4.45mm)
• Height - Seated (Max):0.115" (2.92mm)
