PM42S-100-RC

J.W. Miller / Bourns
In Stock: 174

Can ship immediately

Pricing:
  • 1$0.704
  • 1,000$0.704

Quote It

Technical Details

  • Series:PM42S
  • Package:Tape & Reel (TR)
  • Part Status:Active
  • Type:Wirewound
  • Material - Core:Ferrite
  • Inductance:10 µH
  • Tolerance:±30%
  • Current Rating (Amps):1.3 A
  • Current - Saturation (Isat):1A
  • Shielding:Shielded
  • DC Resistance (DCR):150mOhm Max



  • Q @ Freq:10 @ 2.52MHz
  • Frequency - Self Resonant:38MHz
  • Ratings:-
  • Operating Temperature:-40°C ~ 125°C
  • Inductance Frequency - Test:100 kHz
  • Features:-
  • Mounting Type:Surface Mount
  • Package / Case:Nonstandard
  • Supplier Device Package:-
  • Size / Dimension:0.189" L x 0.189" W (4.80mm x 4.80mm)
  • Height - Seated (Max):0.118" (3.00mm)

Related Products


PM42S-101-RC

FIXED IND 100UH 400MA 1.35OHM SM

PM42S-101-RC Datasheet
  • 1: $0.70400
  • 1000: $0.70400

PM42S-120-RC

FIXED IND 12UH 1.15A 170MOHM SMD

PM42S-120-RC Datasheet
  • 1: $0.70400
  • 1000: $0.70400

PM42S-121-RC

FIXED IND 120UH 330MA 1.95OHM SM

PM42S-121-RC Datasheet
  • 1: $0.70400
  • 1000: $0.70400

PM42S-150-RC

FIXED IND 15UH 1.03A 220MOHM SMD

PM42S-150-RC Datasheet
  • 1: $0.70400
  • 1000: $0.70400

PM42S-180-RC

FIXED IND 18UH 920MA 280MOHM SMD

PM42S-180-RC Datasheet
  • 1: $0.70400
  • 1000: $0.70400

PM42S-181-RC

FIXED IND 180UH 180MA 4 OHM SMD

PM42S-181-RC Datasheet
  • 1: $0.70400
  • 1000: $0.70400

PM42S-220-RC

FIXED IND 22UH 880MA 300MOHM SMD

PM42S-220-RC Datasheet
  • 1: $0.70400
  • 1000: $0.70400

PM42S-270-RC

FIXED IND 27UH 770MA 370MOHM SMD

PM42S-270-RC Datasheet
  • 1: $0.70400
  • 1000: $0.70400

PM42S-2R7-RC
