SRP5030TA-R22M

Technical Details

• Series:SRP5030TA
• Package:Tape & Reel (TR)
• Part Status:Active
• Type:Wirewound
• Material - Core:Carbonyl Powder
• Inductance:220 nH
• Tolerance:±20%
• Current Rating (Amps):15.5 A
• Current - Saturation (Isat):21A
• Shielding:Shielded
• DC Resistance (DCR):4.4mOhm Max

• Q @ Freq:5 @ 100kHz
• Frequency - Self Resonant:155MHz
• Ratings:AEC-Q200
• Operating Temperature:-40°C ~ 150°C
• Inductance Frequency - Test:100 kHz
• Features:-
• Mounting Type:Surface Mount
• Package / Case:Nonstandard
• Supplier Device Package:-
• Size / Dimension:0.224" L x 0.205" W (5.70mm x 5.20mm)
• Height - Seated (Max):0.118" (3.00mm)
