AL01682N0JTS
Elco (AVX)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 82NH 2.5A 9.4 MOHM SMD
- CategoryFixed Inductors
- Datasheet AL01682N0JTS Datasheet
-
ECAD Model
- Share
In Stock: 104
Can ship immediately
Pricing:
- 1$0.7056
- 1,000$0.7056
Quote It
Technical Details
- Series:AL
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Air
- Inductance:82 nH
- Tolerance:±5%
- Current Rating (Amps):2.5 A
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):9.4mOhm Max
- Q @ Freq:100 @ 150MHz
- Frequency - Self Resonant:1.3GHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:150 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.190" L x 0.150" W (4.83mm x 3.81mm)
- Height - Seated (Max):0.165" (4.20mm)
