RL855-222K-RC
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 2.2MH 180MA 11.1OHM TH
- CategoryFixed Inductors
- Datasheet RL855-222K-RC Datasheet
-
ECAD Model
- Share
In Stock: 131
Can ship immediately
Pricing:
- 1$0.7056
- 10$0.6548
- 100$0.4736
- 500$0.36273
- 1,000$0.32243
- 2,500$0.31532
Quote It
Technical Details
- Series:RL855
- Package:Bulk
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:2.2 mH
- Tolerance:±10%
- Current Rating (Amps):180 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):11.1Ohm Max
- Q @ Freq:80 @ 250kHz
- Frequency - Self Resonant:950kHz
- Ratings:-
- Operating Temperature:-30°C ~ 100°C
- Inductance Frequency - Test:1 kHz
- Features:-
- Mounting Type:Through Hole
- Package / Case:Radial, Vertical Cylinder (Open)
- Supplier Device Package:-
- Size / Dimension:0.307" Dia (7.80mm)
- Height - Seated (Max):0.217" (5.50mm)
