PA1320.171NLT
PulseLarsen Antenna
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 180NH 40A 0.48 MOHM
- CategoryFixed Inductors
- Datasheet PA1320.171NLT Datasheet
-
ECAD Model
- Share
In Stock: 145
Can ship immediately
Pricing:
- 1$0.752
- 3,000$0.752
Quote It
Technical Details
- Series:PA1320NL
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:-
- Material - Core:-
- Inductance:180 nH
- Tolerance:±20%
- Current Rating (Amps):40 A
- Current - Saturation (Isat):52A
- Shielding:Shielded
- DC Resistance (DCR):0.48mOhm
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-40°C ~ 130°C
- Inductance Frequency - Test:-
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.410" L x 0.315" W (10.41mm x 8.00mm)
- Height - Seated (Max):0.256" (6.50mm)
