UP2UC-471-R
PowerStor (Eaton)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 470UH 500MA 1.27 OHM
- CategoryFixed Inductors
- Datasheet UP2UC-471-R Datasheet
-
ECAD Model
- Share
In Stock: 113
Can ship immediately
Pricing:
- 1$0.7524
- 600$0.7218
Quote It
Technical Details
- Series:UNI-PAC™ 2UC
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Wirewound
- Material - Core:-
- Inductance:470 µH
- Tolerance:±20%
- Current Rating (Amps):500 mA
- Current - Saturation (Isat):500mA
- Shielding:Unshielded
- DC Resistance (DCR):1.27Ohm Max
- Q @ Freq:-
- Frequency - Self Resonant:3.5MHz
- Ratings:-
- Operating Temperature:-25°C ~ 85°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.500" L x 0.394" W (12.70mm x 10.00mm)
- Height - Seated (Max):0.205" (5.21mm)
