8250-101K-RC
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 100UH 322MA 2.28OHM TH
- CategoryFixed Inductors
- Datasheet 8250-101K-RC Datasheet
-
ECAD Model
- Share
In Stock: 185
Can ship immediately
Pricing:
- 1$0.756
- 1,000$0.684
Quote It
Technical Details
- Series:8250
- Package:Bulk
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:100 µH
- Tolerance:±10%
- Current Rating (Amps):322 mA
- Current - Saturation (Isat):120mA
- Shielding:Shielded
- DC Resistance (DCR):2.28Ohm Max
- Q @ Freq:65 @ 2.5MHz
- Frequency - Self Resonant:12MHz
- Ratings:-
- Operating Temperature:-55°C ~ 105°C
- Inductance Frequency - Test:2.5 MHz
- Features:-
- Mounting Type:Through Hole
- Package / Case:Axial
- Supplier Device Package:-
- Size / Dimension:0.164" Dia x 0.450" L (4.17mm x 11.43mm)
- Height - Seated (Max):-
