PM7032S-6R8M-RC

Technical Details

• Series:PM7032S
• Package:Tape & Reel (TR)
• Part Status:Active
• Type:Wirewound
• Material - Core:Ferrite
• Inductance:6.8 µH
• Tolerance:±20%
• Current Rating (Amps):1.6 A
• Current - Saturation (Isat):1.8A
• Shielding:Shielded
• DC Resistance (DCR):54mOhm Max

• Q @ Freq:17 @ 7.96MHz
• Frequency - Self Resonant:37MHz
• Ratings:-
• Operating Temperature:-40°C ~ 125°C
• Inductance Frequency - Test:100 kHz
• Features:-
• Mounting Type:Surface Mount
• Package / Case:Nonstandard
• Supplier Device Package:-
• Size / Dimension:0.276" L x 0.276" W (7.00mm x 7.00mm)
• Height - Seated (Max):0.134" (3.40mm)
