AIUR-12-470K
Abracon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 47UH 780MA 280 MOHM TH
- CategoryFixed Inductors
- Datasheet AIUR-12-470K Datasheet
-
ECAD Model
- Share
In Stock: 136
Can ship immediately
Pricing:
- 1$0.76607
- 10$0.71135
- 100$0.51436
- 500$0.39398
- 1,000$0.3502
- 2,500$0.33926
Quote It
Technical Details
- Series:AIUR-12
- Package:Bulk
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:47 µH
- Tolerance:±10%
- Current Rating (Amps):780 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):280mOhm Max
- Q @ Freq:30 @ 100kHz
- Frequency - Self Resonant:5MHz
- Ratings:-
- Operating Temperature:-40°C ~ 85°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Through Hole
- Package / Case:Radial, Vertical Cylinder
- Supplier Device Package:-
- Size / Dimension:0.283" Dia (7.20mm)
- Height - Seated (Max):0.413" (10.50mm)
