CDRH104RT125NP-2R2PC
Sumida Corporation- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 2.2UH 7.1A 11 MOHM SMD
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 126
Can ship immediately
Pricing:
- 1$0.7936
Quote It
Technical Details
- Series:CDRH104R/T125
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:-
- Material - Core:Ferrite
- Inductance:2.2 µH
- Tolerance:±25%
- Current Rating (Amps):7.1 A
- Current - Saturation (Isat):8A
- Shielding:Shielded
- DC Resistance (DCR):11mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:AEC-Q200
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.402" L x 0.394" W (10.20mm x 10.00mm)
- Height - Seated (Max):0.157" (4.00mm)
