UP0.4C-150-R
PowerStor (Eaton)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 15UH 950MA 250 MOHM
- CategoryFixed Inductors
- Datasheet UP0.4C-150-R Datasheet
-
ECAD Model
- Share
In Stock: 194
Can ship immediately
Pricing:
- 1$0.795
- 2,500$0.7635
Quote It
Technical Details
- Series:UNI-PAC™ 0.4C
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:15 µH
- Tolerance:±20%
- Current Rating (Amps):950 mA
- Current - Saturation (Isat):940mA
- Shielding:Unshielded
- DC Resistance (DCR):250mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-40°C ~ 85°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.260" L x 0.175" W (6.60mm x 4.45mm)
- Height - Seated (Max):0.115" (2.92mm)
