PG0437.601NLT
PulseLarsen Antenna
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 600NH 18A 0.85 MOHM
- CategoryFixed Inductors
- Datasheet PG0437.601NLT Datasheet
-
ECAD Model
- Share
In Stock: 108
Can ship immediately
Pricing:
- 1$0.9145
- 2,250$0.9145
Quote It
Technical Details
- Series:PG0437NL
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:-
- Material - Core:-
- Inductance:600 nH
- Tolerance:±20%
- Current Rating (Amps):18 A
- Current - Saturation (Isat):21A
- Shielding:Unshielded
- DC Resistance (DCR):0.85mOhm
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-40°C ~ 130°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.492" L x 0.433" W (12.50mm x 11.00mm)
- Height - Seated (Max):0.177" (4.50mm)
