4232R-562K
API Delevan
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 5.6UH 322MA 2 OHM SMD
- CategoryFixed Inductors
- Datasheet 4232R-562K Datasheet
-
ECAD Model
- Share
In Stock: 191
Can ship immediately
Pricing:
- 1$1.13762
- 2,000$0.90652
Quote It
Technical Details
- Series:4232R
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Wirewound
- Material - Core:Iron
- Inductance:5.6 µH
- Tolerance:±10%
- Current Rating (Amps):322 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):2Ohm Max
- Q @ Freq:30 @ 7.9MHz
- Frequency - Self Resonant:36MHz
- Ratings:-
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:7.9 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:2-SMD
- Supplier Device Package:-
- Size / Dimension:0.138" L x 0.105" W (3.51mm x 2.67mm)
- Height - Seated (Max):0.101" (2.57mm)
