1210R-681K
API Delevan
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 680NH 588MA 600 MOHM
- CategoryFixed Inductors
- Datasheet 1210R-681K Datasheet
-
ECAD Model
- Share
In Stock: 171
Can ship immediately
Pricing:
- 1$1.1169
- 500$0.8064
Quote It
Technical Details
- Series:1210R
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:-
- Material - Core:Iron
- Inductance:680 nH
- Tolerance:±10%
- Current Rating (Amps):588 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):600mOhm Max
- Q @ Freq:30 @ 25MHz
- Frequency - Self Resonant:160MHz
- Ratings:-
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:25 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:1210 (3225 Metric)
- Supplier Device Package:1210
- Size / Dimension:0.128" L x 0.095" W (3.25mm x 2.42mm)
- Height - Seated (Max):0.101" (2.57mm)
