SPD42R-332M
API Delevan
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 3.3UH 1.1A 32 MOHM SMD
- CategoryFixed Inductors
- Datasheet SPD42R-332M Datasheet
-
ECAD Model
- Share
In Stock: 139
Can ship immediately
Pricing:
- 1$1.9904
- 500$1.7728
Quote It
Technical Details
- Series:SPD42R
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:3.3 µH
- Tolerance:±20%
- Current Rating (Amps):1.1 A
- Current - Saturation (Isat):1.1A
- Shielding:Shielded
- DC Resistance (DCR):32mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:65MHz
- Ratings:-
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.185" L x 0.185" W (4.70mm x 4.70mm)
- Height - Seated (Max):0.115" (2.92mm)
