ELJ-FAR68MF2

Technical Details

• Series:FA
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Obsolete
• Type:Wirewound
• Material - Core:-
• Inductance:680 nH
• Tolerance:±20%
• Current Rating (Amps):260 mA
• Current - Saturation (Isat):-
• Shielding:Unshielded
• DC Resistance (DCR):550mOhm Max

• Q @ Freq:25 @ 25.2MHz
• Frequency - Self Resonant:135MHz
• Ratings:-
• Operating Temperature:-20°C ~ 85°C
• Inductance Frequency - Test:25.2 MHz
• Features:-
• Mounting Type:Surface Mount
• Package / Case:1210 (3225 Metric)
• Supplier Device Package:-
• Size / Dimension:0.126" L x 0.098" W (3.20mm x 2.50mm)
• Height - Seated (Max):0.094" (2.40mm)
