PM105-121K

Technical Details

• Series:PM105
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Obsolete
• Type:Wirewound
• Material - Core:Ferrite
• Inductance:120 µH
• Tolerance:±10%
• Current Rating (Amps):890 mA
• Current - Saturation (Isat):-
• Shielding:Unshielded
• DC Resistance (DCR):400mOhm

• Q @ Freq:-
• Frequency - Self Resonant:6MHz
• Ratings:-
• Operating Temperature:-30°C ~ 100°C
• Inductance Frequency - Test:1 kHz
• Features:-
• Mounting Type:Surface Mount
• Package / Case:Nonstandard
• Supplier Device Package:-
• Size / Dimension:0.386" L x 0.386" W (9.80mm x 9.80mm)
• Height - Seated (Max):0.228" (5.80mm)
