ELJ-FB561JF
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 560UH 50MA 35 OHM SMD
- CategoryFixed Inductors
- Datasheet ELJ-FB561JF Datasheet
-
ECAD Model
- Share
In Stock: 142
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:FB
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Obsolete
- Type:Wirewound
- Material - Core:-
- Inductance:560 µH
- Tolerance:±5%
- Current Rating (Amps):50 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):35Ohm Max
- Q @ Freq:30 @ 796kHz
- Frequency - Self Resonant:2.7MHz
- Ratings:-
- Operating Temperature:-20°C ~ 85°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:1812 (4532 Metric)
- Supplier Device Package:1812
- Size / Dimension:0.177" L x 0.126" W (4.50mm x 3.20mm)
- Height - Seated (Max):0.134" (3.40mm)
