ELJ-NJR15JF2

Technical Details

• Series:NJ
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Obsolete
• Type:Wirewound
• Material - Core:Non-Magnetic
• Inductance:150 nH
• Tolerance:±5%
• Current Rating (Amps):160 mA
• Current - Saturation (Isat):-
• Shielding:Unshielded
• DC Resistance (DCR):1.3Ohm Max

• Q @ Freq:32 @ 150MHz
• Frequency - Self Resonant:1.4GHz
• Ratings:-
• Operating Temperature:-40°C ~ 85°C
• Inductance Frequency - Test:150 MHz
• Features:-
• Mounting Type:Surface Mount
• Package / Case:0603 (1608 Metric)
• Supplier Device Package:0603 (1608 Metric)
• Size / Dimension:0.063" L x 0.031" W (1.60mm x 0.80mm)
• Height - Seated (Max):0.031" (0.80mm)
