PM3316S-1R5M
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 1.5UH 4.5A 22 MOHM SMD
- CategoryFixed Inductors
- Datasheet PM3316S-1R5M Datasheet
-
ECAD Model
- Share
In Stock: 134
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:PM3316S
- Package:Tape & Reel (TR)
- Part Status:Obsolete
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:1.5 µH
- Tolerance:±20%
- Current Rating (Amps):4.5 A
- Current - Saturation (Isat):5.2A
- Shielding:Shielded
- DC Resistance (DCR):22mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-40°C ~ 85°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.512" L x 0.374" W (13.00mm x 9.50mm)
- Height - Seated (Max):0.201" (5.10mm)
