CDRH104R-7R0NC

Technical Details

• Series:CDRH104R
• Package:Tape & Reel (TR)
• Part Status:Obsolete
• Type:-
• Material - Core:-
• Inductance:7 µH
• Tolerance:±30%
• Current Rating (Amps):4.5 A
• Current - Saturation (Isat):4.8A
• Shielding:Shielded
• DC Resistance (DCR):27mOhm Max

• Q @ Freq:-
• Frequency - Self Resonant:-
• Ratings:-
• Operating Temperature:-40°C ~ 100°C
• Inductance Frequency - Test:100 kHz
• Features:-
• Mounting Type:Surface Mount
• Package / Case:Nonstandard
• Supplier Device Package:-
• Size / Dimension:0.402" L x 0.394" W (10.20mm x 10.00mm)
• Height - Seated (Max):0.157" (4.00mm)
