CPL2512T1R0M

Technical Details

• Series:CPL
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Obsolete
• Type:Wirewound
• Material - Core:Ferrite
• Inductance:1 µH
• Tolerance:±20%
• Current Rating (Amps):1.3 A
• Current - Saturation (Isat):1.5A
• Shielding:Shielded
• DC Resistance (DCR):117mOhm Max

• Q @ Freq:-
• Frequency - Self Resonant:-
• Ratings:-
• Operating Temperature:-40°C ~ 105°C
• Inductance Frequency - Test:-
• Features:-
• Mounting Type:Surface Mount
• Package / Case:Nonstandard
• Supplier Device Package:-
• Size / Dimension:0.098" L x 0.059" W (2.50mm x 1.50mm)
• Height - Seated (Max):0.047" (1.20mm)
