SCR105B-680

Technical Details

• Series:SCR105B
• Package:Tape & Reel (TR)
• Part Status:Obsolete
• Type:-
• Material - Core:-
• Inductance:68 µH
• Tolerance:±20%
• Current Rating (Amps):1.66 A
• Current - Saturation (Isat):850mA
• Shielding:Shielded
• DC Resistance (DCR):210mOhm Max

• Q @ Freq:-
• Frequency - Self Resonant:-
• Ratings:-
• Operating Temperature:-40°C ~ 125°C
• Inductance Frequency - Test:2.52 kHz
• Features:-
• Mounting Type:Surface Mount
• Package / Case:Nonstandard
• Supplier Device Package:-
• Size / Dimension:0.413" L x 0.374" W (10.50mm x 9.50mm)
• Height - Seated (Max):0.217" (5.50mm)
