IR02EV330K

Technical Details

• Series:IR
• Package:Tape & Reel (TR)
• Part Status:Obsolete
• Type:-
• Material - Core:Ferrite
• Inductance:33 µH
• Tolerance:±10%
• Current Rating (Amps):130 mA
• Current - Saturation (Isat):-
• Shielding:Unshielded
• DC Resistance (DCR):3.4Ohm Max

• Q @ Freq:45 @ 2.5MHz
• Frequency - Self Resonant:24MHz
• Ratings:-
• Operating Temperature:-55°C ~ 105°C
• Inductance Frequency - Test:2.5 MHz
• Features:-
• Mounting Type:Through Hole
• Package / Case:Axial
• Supplier Device Package:-
• Size / Dimension:0.120" Dia x 0.260" L (3.05mm x 6.60mm)
• Height - Seated (Max):-
