CM322522-R10ML
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 100NH 360MA 300MOHM SM
- CategoryFixed Inductors
- Datasheet CM322522-R10ML Datasheet
-
ECAD Model
- Share
In Stock: 185
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:CM322522
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Obsolete
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:100 nH
- Tolerance:±20%
- Current Rating (Amps):360 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):300mOhm Max
- Q @ Freq:10 @ 100MHz
- Frequency - Self Resonant:450MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.126" L x 0.098" W (3.20mm x 2.50mm)
- Height - Seated (Max):0.087" (2.20mm)
