PM125S-820M-RC

Technical Details

• Series:PM125S
• Package:Tape & Reel (TR)
• Part Status:Obsolete
• Type:Wirewound
• Material - Core:Ferrite
• Inductance:82 µH
• Tolerance:±20%
• Current Rating (Amps):1.14 A
• Current - Saturation (Isat):1.82A
• Shielding:Shielded
• DC Resistance (DCR):200mOhm Max

• Q @ Freq:-
• Frequency - Self Resonant:8MHz
• Ratings:-
• Operating Temperature:-40°C ~ 125°C
• Inductance Frequency - Test:2.52 MHz
• Features:-
• Mounting Type:Surface Mount
• Package / Case:Nonstandard
• Supplier Device Package:-
• Size / Dimension:0.496" L x 0.457" W (12.60mm x 11.60mm)
• Height - Seated (Max):0.232" (5.90mm)
