ATS-FPX025025030-47-C3-R0
Advanced Thermal Solutions, Inc.
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionHEATSINK 25X25X30MM L-TAB FP
- CategoryThermal - Heat Sinks
- Datasheet ATS-FPX025025030-47-C3-R0 Datasheet
-
ECAD Model
- Share
In Stock: 147
Can ship immediately
Pricing:
- 1$4.29
- 10$4.18996
- 25$4.08223
- 50$3.86754
- 100$3.65275
- 250$3.43789
- 500$3.33043
- 1,000$3.00812
Quote It
Technical Details
- Series:pushPIN™
- Package:Tray
- Part Status:Active
- Type:Top Mount
- Package Cooled:Assorted (BGA, LGA, CPU, ASIC...)
- Attachment Method:Push Pin
- Shape:Square, Fins
- Length:0.984" (25.00mm)
- Width:0.984" (25.00mm)
- Diameter:-
- Fin Height:1.181" (30.00mm)
- Power Dissipation @ Temperature Rise:-
- Thermal Resistance @ Forced Air Flow:9.58°C/W @ 100 LFM
- Thermal Resistance @ Natural:-
- Material:Aluminum
- Material Finish:Blue Anodized
