UVZ1H471MHD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 470UF 20% 50V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UVZ1H471MHD Datasheet
-
ECAD Model
- Share
In Stock: 2,117
Can ship immediately
Pricing:
- 1$0.79
- 10$0.58059
- 100$0.39814
- 500$0.31522
- 1,000$0.26544
- 2,500$0.24885
- 5,000$0.23226
Quote It
Technical Details
- Series:UVZ
- Package:Bulk
- Part Status:Active
- Capacitance:470 µF
- Tolerance:±20%
- Voltage - Rated:50 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:1000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:530 mA @ 120 Hz
- Ripple Current @ High Frequency:795 mA @ 10 kHz
- Impedance:-
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.492" Dia (12.50mm)
- Height - Seated (Max):0.866" (22.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
