ELXZ500ELL221MJ20S
United Chemi-Con
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 220UF 20% 50V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet ELXZ500ELL221MJ20S Datasheet
-
ECAD Model
- Share
In Stock: 1,566
Can ship immediately
Pricing:
- 1$0.94
- 10$0.67284
- 100$0.45615
- 500$0.34787
- 1,000$0.30148
- 2,500$0.28602
- 5,000$0.27056
Quote It
Technical Details
- Series:LXZ
- Package:Bulk
- Part Status:Active
- Capacitance:220 µF
- Tolerance:±20%
- Voltage - Rated:50 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:525 mA @ 120 Hz
- Ripple Current @ High Frequency:1.05 A @ 100 kHz
- Impedance:88 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):0.846" (21.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
