UPM1J471MHD6
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 470UF 20% 63V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UPM1J471MHD6 Datasheet
-
ECAD Model
- Share
In Stock: 6,948
Can ship immediately
Pricing:
- 1$1.23
- 10$0.97244
- 100$0.72948
- 500$0.55112
- 1,000$0.48629
- 2,500$0.45387
- 5,000$0.44091
Quote It
Technical Details
- Series:UPM
- Package:Bulk
- Part Status:Active
- Capacitance:470 µF
- Tolerance:±20%
- Voltage - Rated:63 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:1.36 A @ 120 Hz
- Ripple Current @ High Frequency:1.7 A @ 10 kHz
- Impedance:42 mOhms
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):1.063" (27.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
