UKW2A102MHD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 1000UF 20% 100V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UKW2A102MHD Datasheet
-
ECAD Model
- Share
In Stock: 312
Can ship immediately
Pricing:
- 1$2.91
- 10$2.35598
- 100$1.79945
- 500$1.37099
- 1,000$1.19961
- 2,500$1.16533
Quote It
Technical Details
- Series:UKW
- Package:Bulk
- Part Status:Active
- Capacitance:1000 µF
- Tolerance:±20%
- Voltage - Rated:100 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 85°C
- Operating Temperature:-40°C ~ 85°C
- Polarization:Polar
- Ratings:-
- Applications:Audio
- Ripple Current @ Low Frequency:1.37 A @ 120 Hz
- Ripple Current @ High Frequency:1.5755 A @ 10 kHz
- Impedance:-
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.709" Dia (18.00mm)
- Height - Seated (Max):1.575" (40.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
