EEU-TP1V202
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 2000UF 20% 35V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet EEU-TP1V202 Datasheet
-
ECAD Model
- Share
In Stock: 1,092
Can ship immediately
Pricing:
- 1$3.03
- 10$2.44538
- 100$1.90704
- 500$1.41806
- 1,000$1.32025
- 2,500$1.27135
- 5,000$1.24691
Quote It
Technical Details
- Series:TP
- Package:Bulk
- Part Status:Active
- Capacitance:2000 µF
- Tolerance:±20%
- Voltage - Rated:35 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 125°C
- Operating Temperature:-40°C ~ 135°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:2.6 A @ 120 Hz
- Ripple Current @ High Frequency:2.71 A @ 100 kHz
- Impedance:-
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):1.319" (33.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
